Corrugated Sidewall Conveyor Belt

The Corrugated Sidewall Conveyor Belt is specially designed for steep angle and vertical conveying applications, making it ideal for transporting bulk materials where space is limited. It features corrugated sidewalls and cleats, which prevent material spillage and allow efficient conveying at high inclinations.

This belt is widely used in industries such as mining, cement, power plants, ports, and bulk material handling, where materials need to be transported vertically or at steep angles. Its innovative design ensures maximum material retention, high efficiency, and reduced space requirements.

The belt structure includes sidewalls, cleats, and effective width design, allowing customization based on material type and conveying angle

Key Features

• ✔ Suitable for steep angle and vertical conveying
• ✔ Corrugated sidewalls prevent material spillage
• ✔ Cleats ensure efficient material movement
• ✔ High load carrying capacity
• ✔ Space-saving design
• ✔ Durable and long service life
• ✔ Customizable for different applications

Technical Specifications

• Type: Corrugated Sidewall Conveyor Belt
• Structure: Base belt + Sidewalls + Cleats
• Sidewall Height (H): 60 mm – 400 mm
• Cleat Types: C, TC, T, TCS
• Belt Width: Customizable
• Material: Rubber with fabric reinforcement
• Operating Angle: Up to 90° (vertical conveying possible)
• Design: Customized as per application

Applications

• Mining & Quarry
• Cement Industry
• Power Plants
• Ports & Shipping
• Bulk Material Handling
• Fertilizer & Chemical Plants

Optional Features

• Heat resistant sidewall belt
• Oil resistant belt
• Fire resistant options
• Custom cleat design
• High abrasion resistant grade
